Cubic air coolers equipped with radial fans (‘plug fans’) AR with an ingenious plenum system. The AR series is ideal for installation with textile sleeves in workrooms or other similar applications.
Manufactured with stainless steel tubes and aluminium fins (StSt/Al). Optionally can be produced in copper/aluminium. Compatible with all refrigerants (NH₃, CO₂, glycol, HFC, etc.). Modular design from 1 to 5 radial fans (Ø500, 630). Fin pitch: 4.5-6-7 mm.
AR series evaporators are high efficiency industrial cubic evaporators. Equipped with radial fans as standard with an ingenious plenum system, and textile sleeve adapters. Our robust AR evaporators offer high performance and are highly resistant to corrosion.
They are ideal for installation with textile sleeves in workrooms or other similar applications.
They stand out for their very low sound pressure level, which is essential for their application.
Features
- Tube material. Stainless steel AISI 304 (AISI 316 on request) or Cu/Al
- Aluminium fins. Optionally, they can be made of magnesium aluminium or aluminium with epoxy protection
- Stainless steel screws
- White thermo-lacquered aluminium casing
- Removable side covers. Easy access to coolant connections
- Tray insulated with polyurethane as standard to avoid condensation. Tray made entirely of GRP (fiberglass reinforced polyester), a light and resistant material, rigid, resistant to corrosion and a good thermal, acoustic and electrical insulator
- ErP Ready axial fans with IP54 or IP55 motors, depending on the model; motor protection with thermocontacts
- The equipment is delivered pressurized and with Schrader + valves
Accessories
- Hot gas defrost in tray with check valve installed (optional)
- Electric defrosting in coil and/or tray
- Connection to textile sleeves
- EC fans
- Epoxy protected sheets
- Stainless steel casing
